Scale WordPress Sites with MySQL Replicas and HyperDB

Learn how to distribute requests to replica MySQL databases on WordPress using HyperDB.

Discuss in our Forum Discuss in Slack

This section provides information on how to scale your WordPress site with MySQL Replicas and HyperDB.

 Note

Replica MySQL databases are available for sites on the Elite service level. Contact sales to inquire about our Elite plans.

Advantages of MySQL Replication

Typical WordPress sites are limited to the capacity of a single database to serve read and write requests. As a result, high traffic sites can experience latency as requests are fulfilled. MySQL replication rapidly copies content from the primary database to a replica database. This allows you to spread requests across multiple databases to improve site performance and load times.

About HyperDB

HyperDB is a drop-in plugin that replaces the standard wpdb class. This allows WordPress to write and read from additional database servers. HyperDB supports:

  • Database replication
  • Failover
  • Load balancing
  • Partitioning

Keep in mind, HyperDB is a powerful tool with several tuning options based on database architecture and network topology. Before you implement a complex configuration, it’s best to see if a simpler configuration suits your needs.

Install and Configure HyperDB

A Customer Success Manager (CSM) must change your site service level to Elite before you can install HyperDB. The Pantheon platform will automatically configure and manage your primary and replica databases. Contact us to learn more about service levels and how a CSM can help.

Complete the steps below after your site service level has been updated to Elite.

  1. Download the archive of HyperDB from the WordPress plugin repository and move the db.php file into the /wp-content directory. This is a drop-in plugin and does not require activation at any time.

  2. Configure the primary and replica databases within db-config.php. This file should be stored within the same directory as the site's wp-config.php file.

  3. Deploy the db.php database drop-in to production. WordPress will start allocating MySQL database reads and writes based on the configuration details you’ve provided in db-config.php.

The following sample configurations can be used in place of the dp-config.php file provided within the plugin archive. These examples require no additional edits for sites running on Pantheon. For more advanced options, refer to the db-config.php file provided in the HyperDB plugin archive.

Split Reads Between Primary and Replica

You can split reads between the primary and the replica database to distribute the load between two servers.

<?php
/**
 * Register the primary server to HyperDB
 */
$wpdb->add_database( array(
        'host'     => DB_HOST,
        'user'     => DB_USER,
        'password' => DB_PASSWORD,
        'name'     => DB_NAME,
        'write'    => 1, // primary server takes write queries
        'read'     => 1, // ... and read queries
) );
/**
 * Register replica database server if it's available in this environment
 */
if ( ! empty( $_ENV['REPLICA_DB_HOST'] ) ) {
        $wpdb->add_database(array(
                'host'     => $_ENV['REPLICA_DB_HOST'] . ':' . $_ENV['REPLICA_DB_PORT'],
                'user'     => $_ENV['REPLICA_DB_USER'],
                'password' => $_ENV['REPLICA_DB_PASSWORD'],
                'name'     => $_ENV['REPLICA_DB_NAME'],
                'write'    => 0, // replica doesn't take write queries
                'read'     => 1, // ... but it does take read queries
        ));
}
// That's it!

Pass Frontend Read Queries to Replica, WordPress Dashboard Reads and Writes to Primary

You can pass all frontend database read queries to the replica. This leaves the primary database dedicated to WordPress dashboard reads and writes. This setup can help ensure WordPress dashboard availability during times of high frontend load.

You should use some form of cache fallback if reads to the replica begin failing.

<?php
/**
 * Use HyperDB to just use the replica for frontend reads.
 * Register the primary server to HyperDB
 */
$wpdb->add_database( array(
        'host'     => DB_HOST,
        'user'     => DB_USER,
        'password' => DB_PASSWORD,
        'name'     => DB_NAME,
        'write'    => 1, // primary server takes write queries
        'read'     => is_admin() || empty( $_ENV['REPLICA_DB_HOST'] ) ? 1 : 0, // ... but only takes read queries in the admin if the replica is available
) );
/**
 * Register replica database server if it's available in this environment
 */
if ( ! empty( $_ENV['REPLICA_DB_HOST'] ) && ! is_admin() ) {
        $wpdb->add_database(array(
                'host'     => $_ENV['REPLICA_DB_HOST'] . ':' . $_ENV['REPLICA_DB_PORT'],
                'user'     => $_ENV['REPLICA_DB_USER'],
                'password' => $_ENV['REPLICA_DB_PASSWORD'],
                'name'     => $_ENV['REPLICA_DB_NAME'],
                'write'    => 0, // replica doesn't take write queries
                'read'     => 1, // ... but it does take read queries
        ));
}
// That's it!
